Good Quality Cheap Generator 200w Ultrasonic 25khz Transducer Driver
Brief Introduction of Ultrasonic Cleaning Transducer Driver Circuit
- Frequency:from 17khz to 135khz
- Power: under 300w
- Voltage : AC 220V (15 ~ + 10% ), 60 hz
- AC 110V (15 ~ + 10 %), 50 hz
- Working Temperature: – 10 ℃ to 40 ℃
- Working Humidity: 35 ~ 85%
Some Application of Ultrasonic Cleaning Transducer Driver Circuit
Features of Ultrasonic Cleaning Transducer Driver Circuit
- PCB: double-sided with two ounces.
- Stable working performance
- Large radiator
- Display working states: such as working frequency,current on the display panel.
- For under 40khz PCB generator with digital panel: its power,time and frequency from 17khz to 45khz can be adjusted.
- For above 45khz PCB generator with digital panel: its power and time can be adjusted.its frequency can not be adjusted.
The Specification of Ultrasonic Cleaning Transducer Driver Circuit
|Ultrasonic Cleaning Transducer Driver Circuit
|Ultrasonic Cleaning Transducer Driver Circuit Connection
|Remark: We will supply the required Voltage as need.
|Ultrasonic Cleaning Transducer Driver Circuit Connection Notes
Wiring instructions between Ultrasonic Cleaning Transducer Driver Circuit and Ultrasonic Transducer
|The circuit board can't power on under no-load condition
|After installed, we can not power on until lay cleaning fluid
|Ultrasonic transducer has two lugs.The positive one lay in the middle of two pieces of ceramic.The native one near lower metal column. Please do not make wrong when wiring.
|The larger side with screw hole in ceramic transducer which has a function of vibration,can be stuck in the bottom of cleaning machine. And please make sure the cleaning machine is safely grounding.
|The ceramic transducer should be pasted in the bottom of cleaning machine using transducer specialized glue or use AB glue stick. but the effect is a bit poor, or use epoxy resin with proportion of 10:4.
|Two transducers connected on the circuit board in parallel. Usually, one circuit board connect maximum two transducers. And it also can matched with one transducer.
|AC stands for 110 v mains line and zero line;OUT+ connect the positive pole of transducer.OUT- connect the negative pole of transducer. Please make sure the wiring way is correct between OUT and transducer. If there is any question, please consult us in time to ensure safety.AC stands for 110 v mains line and zero line;OUT+ connect the positive pole of transducer.OUT- connect the negative pole of transducer. Please make sure the wiring way is correct between OUT and transducer. If there is any question, please consult us in time to ensure safety.
|The working circuit board voltage is 600V.The voltage output to the transducer is 1100 v.Please ensure the cleaning machine is safely grounding. Please make sure leakage protect switch assembled on the power supply in order to ensure safety.
